HSM 65/70/80

Home ] [ HSM 65/70/80 ] HSM 90/100 ]



The Compact low level models shred all types of paperwork, such as tax records, account statements, doctors bills - all reliably. Security levels 2 and 3 are optimally adjusted to the requirement in small offices or for the workplace at home.



HSM 65 and HSM 70
Handling :
• Automatic start/stop control
• Standby operation without energy consumption
• Loading width 225 mm (>DIN A4)
• Simple handling
• Compact dimensions
• Rocker switch for On/Off and reversing
HSM 65 :
• Very compact shredder, without container
• Can be fitted on all conventional paper bins
• Pull out suppor
HSM 70 :
• Integrated container, can also be used as paper bin
• 14 litres capacity
• Opening for throwing in normal paperwork

Technical Advantages :
• Hardened full-steel cutting rollers, unaffected by paper clips and staples
• Powerful drive for high performance - motor with thermal protection
• Low noise operation
• Sturdy housing
• Enclosed, proven toothed gearing prevents soiling and wear and thus extends the service life

HSM 80
Handling:
• Automatic start/stop control
• Standby operation without energy consumption
• Loading width 225 mm (>DINA4)
• Simple handling
• Compact dimensions - suitable for any office desk
• Rocker switch for On/Off and reversing
• Integrated container can also be used as paper bin for normal paperwork
• 16 litres capacity

Technical advantages:
• Hardened full-steel cutting rollers, unaffected bypaper clips and staples
• Powerful drive for high performance - motor with thermal protection
• Low noise operation
• Enclosed, proven toothed gearing prevents soiling and wear and thus extends the service life
• Available as strip or particle cut version at various security levels



  HSM 65 HSM 70 HSM 80
Cutting style

Strip cut

Strip cut

Strip cut

Particle cut

Cutting size

3.9 mm

3.9mm

5.8 mm / 3.9 mm

3.5 x 25 mm

Data Security level din 32757-1

2

2

2/2

3

Cutting capacity*

4-6 sheets

4-6 sheets

10-12/7-8 sheets

3-4 sheets

Cutting speed

80 mm/s

80 mm/s

80 mm/s

80mm/ s

Loading width

225 mm

225 mm

225 mm

225 mm

Power**

8OW

8OW

100 W

100 W

Voltage

230V/50Hz

230V/50Hz

230V/50Hz

230V/50Hz

Dimensions in W x D x H in mm

297x126x75

297x180x339

305 x 200 x 380

305 x 200 x 380

Weight

1.4kg

1.8kg

3.5kg

3.5kg

Capacity

-

141

161

161

*perrun DIN A4,70g/m' ** for max. number of sheets

Technical and optical modifications reserved.
